Specifications
| Category | Item | Unit | DRT140 Pneumatic Roller |
| Masses | Operating mass | kg | 14,000 |
| Max weight | kg | 30,000 | |
| Compaction | Rolling width | mm | 2,370 |
| Tyre overlap | mm | 52 | |
| Wheel loads, without ballast | kg | 1,556 | |
| Wheel loads, with max. ballast | kg | 2,889 | |
| Tyre pressure, min | kPa | 380 | |
| Tyre pressure, max | kPa | 780 | |
| Tyre type (smooth) | – | 13/80-20 | |
| Water spray system, type | – | Pressurized | |
| Water spray system, tank capacity | L | 600 | |
| Water spray system, spray nozzle | – | one per tyre | |
| Traction | Speed low | km/h | 7 |
| Speed high | km/h | 18 | |
| Engine | Manufacturer/Model | – | Cummins 4BTAA3.9 II/T2 |
| Type | – | Water-cooled turbo diesel | |
| Rated power | kW (hp) @ rpm | 93 (125) @ 2200 | |
| Fuel tank capacity | L | 320 | |
| Electrical system | V | 24 | |
| Hydraulic System | Driving | – | Variable displacement axial piston pump + motor |
| Steering | – | Constant displacement gear pump | |
| Service brake | – | Drum brakes | |
| Parking/Emergency brake | – | Failsafe multi-disc brakes in gearbox | |
| Dimensions | Wheelbase | mm | 4250 |
| Width | mm | 2370 | |
| Height (with canopy) | mm | 3080 | |
| Height (without canopy) | mm | 2430 | |
| Ground clearance | mm | 350 | |
| Length | mm | 5310 | |
| Turning radius (outside) | mm | 9000 |
